Automatic CZ Purlin Roll Forming Machine | Variable Size Steel Purlin Making Machine
Product Overview
This variable-size automatic CZ purlin roll forming machine is a professional steel structure processing equipment independently developed for industrial building purlin production. Adopting integrated cold roll forming technology,
the equipment realizes free conversion of variable-section C and Z steel purlins without roller replacement. Featuring heavy-duty welded frame and high-precision forming system, the whole line achieves automatic feeding, flattening,
punching, forming and flying shear cutting. It solves the problems of single production function and low efficiency of traditional purlin machines, perfectly matching large-scale and diversified purlin processing demands for domestic
and overseas steel structure projects.
Main Workflow Of c z purlin roll forming machine
c z steel purlin roll forming machine
Uncoiler → Molding core → Hydraulic System → Automatic Control system → Step Formed Mechanism → Automatic Shearing Mechanism → Products Receiving Tables
Unique Product Features
-
Variable Size Adjustable Design: The machine supports stepless adjustment of C/Z purlin height and width, covering multiple common specifications. One device can meet the production of various purlin sizes, greatly reducing customer equipment procurement and site placement costs.
-
Non-stop Servo Cutting System: Equipped with high-speed servo synchronous tracking shear device, it realizes continuous feeding and uninterrupted cutting. The cutting flatness is high with zero burrs, and the fixed-size precision fully meets engineering construction standards.
-
Heavy-duty Gearbox Drive System: Adopts integral hard tooth surface gearbox transmission instead of traditional chain drive. The transmission is stable with low noise, strong bearing capacity and almost no wear, adapting to long-time uninterrupted industrial production.
-
Premium Wear-resistant Forming Rollers: All forming rollers are made of high-quality alloy steel with precision finishing and hard chrome surface treatment. The rollers feature high hardness, strong wear resistance and non-deformation, ensuring long-term consistent forming accuracy of profiles.
-
Intelligent Integrated Control: Equipped with industrial PLC and full-color touch screen, supporting one-key parameter setting, automatic counting and fault self-detection. Multi-language system is available for convenient operation for global users.
Complete Technical Parameters
-
Suitable Processing Materials: Hot-dip galvanized steel, color coated steel coil
-
Processable Material Thickness: 1.5mm - 3.0mm thick steel strip
-
Production Specification Range: Adjustable 80-300mm C/Z type steel purlin
-
Operational Production Speed: 12-20 meters per minute
-
Transmission Structure: Full gearbox hard tooth surface synchronous drive
-
Cutting Mode: Hydraulic servo tracking non-stop flying shear
-
Control Configuration: Siemens PLC + Human-machine touch screen
-
Feeding Equipment: 3T full-automatic hydraulic expansion decoiler
-
Forming Stations: 18 groups of precision forming roller stations
-
Production Mode: Fully automatic continuous cycle production
Standard Production Line Configuration
The complete CZ purlin production line is fully equipped with standard supporting equipment, including hydraulic automatic uncoiling machine, sheet leveling correction device, automatic hole punching mechanism, main roll forming host,
servo fixed-length cutting system, finished product stacking table and complete electrical control system. All core electrical and hydraulic components adopt international well-known brands to ensure stable operation, low failure rate and
long service life of the whole equipment.
Industry Application Scenarios
The equipment is specially used for mass production of C-type and Z-type steel purlins, which are widely applied in steel structure industrial workshops, logistics warehouses, large-span stadiums, exhibition halls, high-rise steel structure buildings
and solar photovoltaic power station support systems. The produced purlins have uniform specifications, good structural stability and strong bearing capacity, which are essential core components for modern light steel buildings.
Professional After-sales & Custom Service
-
Reliable Quality Warranty: The main frame and forming system enjoy long-term quality warranty, with lifelong free technical consultation service.
-
Global Technical Guidance: Provide professional equipment installation manuals, remote video debugging and operational training to solve user operation problems in real time.
-
Personalized Customization: Support customized punching hole spacing, hole type and special purlin size production according to customer project drawings.
-
Timely Spare Parts Supply: Sufficient spare parts inventory, fast delivery of wearing parts to ensure normal production progress of customers.
-
Efficient Delivery Service: Standard models are in stock, customized equipment has a standardized production cycle to meet customer project delivery requirements.
