1.Net Weight:2800kg
2.Machine Dimension:5800×1200×1800mm
3.Raw Material Thickness:0.3 - 0.8mm
4.Forming Speed: 8 - 15m/min
5.Email:xinnuo05@xinnuomachine.com
6.Email:xinnuo05@xinnuomachine.com
| Basic Information |
Model Number | TPF - 2024A |
| Machine Dimension | 5800×1200×1800mm | |
| Net Weight | 2800kg | |
| Power Supply |
380V/50Hz/3P | |
| Forming Performance | Raw Material Thickness | 0.3 - 0.8mm |
| Forming Speed | 8 - 15m/min | |
| Trapezoidal Plate Specification | Bottom Width: 100 - 400mm
|
|
| Forming Accuracy | ±0.2mm | |
| Mechanical System | Roller Material | 45# Steel18 - 22 + Hard Chrome Plating |
| Number of Forming Rollers | 18 - 22rollers | |
| Pressure System | Hydraulic Drive | |
| Control System | Control Mode | PLC + Touch Screen |
| Cutting Device | Hydraulic Shearing | |
| Safety Protection | Emergency Stop Button, Safety Light Curtain | |
| Auxiliary Functions | Decoiling Device | Max. Decoiling Diameter: 1200mm |
| Material Guide System | Automatic Centering Guide | |
| Lubrication System | Automatic Quantitative Lubrication |
package
1. The main machine is covered by plastic film.
2. PLC control box, spare parts and other small parts are packed by wooden carton box.
3. If the machine is too long, we will divide it into two parts and pack them in one package with steel wire.
4. Rollers and shafts are covered with anti-rust oil.
5. Manual decoiler was nude packing.
6. The output-table put into a carton box.
7. Fit for ocean shipping.
8. Spare parts in a carton box.
9. Manual decoiler was nude packing.
At XINNUO, we are committed to delivering high-performance metal roll forming machines tailored for global industrial needs. Our equipment offers reliable and flexible production capabilities to meet the demands of modern construction and manufacturing industries.
