corrugated roof panel forming machine

Product Attributes :

1.Machine Dimensions:6,800×1,500×2,000mm (L×W×H)

2.Power Supply:380V/50Hz (three-phase)

3.Cutting Precision:±0.5mm (for sheets with length ≤3 meters)

4.Payment Terms:30% T/T in advance,70% when shipping

5.Email:xinnuo05@xinnuomachine.com

6.WhatsApp：+8618830702960

Product Description

Product Description of Corrugated Forming Machine

This corrugated forming machine is a high-performance and intelligent equipment specially designed for the production of corrugated sheets (widely used in construction, packaging, and transportation industries). It integrates advanced servo drive technology, precision mechanical transmission, and intelligent control systems to achieve efficient, stable, and high-quality corrugated forming processes.

With a fully automated operation flow—from raw material feeding, precise rolling forming, to cutting and stacking—the machine significantly reduces manual intervention, lowers labor costs, and improves production efficiency by up to 30% compared to traditional equipment. It supports flexible adjustment of corrugated specifications (such as wave height, wave pitch, and sheet thickness) to meet the diverse needs of different application scenarios, whether it is for light steel keels in construction, corrugated packaging boxes, or protective covers for mechanical parts.

In addition, the machine is equipped with a high-definition touch screen control panel, which allows real-time monitoring of production parameters (such as speed, temperature, and yield) and one-click troubleshooting, ensuring easy operation and low maintenance difficulty. Its body is made of high-strength steel, with a corrosion-resistant coating on the surface, effectively extending the service life to 8-10 years. It also complies with international safety standards, with emergency stop buttons, safety guards, and overload protection functions to fully guarantee the safety of operators.

Applicable Raw Material	Galvanized steel sheet, aluminum sheet; thickness: 0.3-1.2mm
Forming Capacity	Max. 15 meters per minute; daily output (8h): 7,200 meters (based on standard specs)
Corrugated Specifications	Wave height: 5-30mm; Wave pitch: 20-80mm (adjustable via touch screen)
Cutting Precision	±0.5mm (for sheets with length ≤3 meters)
Power Supply	380V/50Hz (three-phase); Rated power: 18.5kW
Machine Dimensions	6,800×1,500×2,000mm (L×W×H)
Net weight:	4,200kg
Control System	PLC (Siemens S7-1200); 10-inch color touch screen (HMI)
Feeding Method	Automatic decoiler (max. coil weight: 5 tons); with deviation correction function
Cooling System	Water-cooled (for forming rollers); temperature control range: 30-60℃
Safety Features	Emergency stop button, safety light curtain, overload protection, voltage stabilization
Warranty Period	1 year (for whole machine)
