Power :380V/3PH/50HZ
Roller Shaft Diameter: 80
Forming Speed:8-15 m/min
Width:customize
WhatsApp:+8618830702960
Smartech Machinery hydraulic automatic cz purlin touch screen forming machine consists of a decoiler, feeding device, leveling device, punching device, cutting device,
roll forming stations, and an electric controlling system. You can also require automatic stackers as an option. For punching distance and sheet length, you can input
parameters via the touch screen, allowing the sheets to be punched and cut at the set length through PLC and Encoder control. This system supports various configurations,
including the single Z purlin forming machine,u purlin roll forming machine and changeable u purlin roll forming machine, making it a fully automatic and continuous forming
solution for producing high-precision purlins.
|
Steel Purlin Roll Forming Equipment |
||
| 1.In-put material | Guiding shaft and guiding rollers | |
| 2. Flatten | Up three down four additional two stations guiding and sending ,at the same time full solid shaft heat treatment with blasting and chroming. | |
| 3. Forming | 18 stations of main forming (inside 1 station for forming flange, meanwhile 87-95 degree adjustable), then 13 stations CZ change mould, turnover 180 degree to finish the change. Changing the Specification size on Touchscreen.ad | |
| 4. Rib forming | diagonal rib roller 2 sets | |
| 5. Straighten | 10 rollers CZ special-use double axis straightening and 4 rollers double axis straightening, total 2 straightening units. | |
| 6. Guiding and sending | driven by up and down gears | |
| 7. Punch | punch single hole (D14, D16) on web and dual hole (26×16, 26×14) on web , dual hole (26×16, 26×14) on flange | |
| 8. Formed-cut | step-less cutting system, meantime no need change blade, universal size 80-300 blade. | |
Versatility: Capable of producing multiple sizes of profiles or (C, Z, U, M) with quick changeover.
High Efficiency: Produces large quantities of purlins in a relatively short amount of time.
Consistency: Ensures uniformity and precision in the produced purlins.
Customization: Adjustable rollers and punching systems allow for various sizes and hole patterns.
Durability: Built to handle heavy-duty materials and continuous operation.
At XINNUO, we are committed to delivering high-performance metal roll forming machines tailored for global industrial needs. Our equipment offers reliable and flexible production capabilities to meet the demands of modern construction and manufacturing industries.
