Main Roll Forming Machine
1. It adopts three layers structure; each layer is separated designed to produce one type of profile sheet.
2. Roll stations: 16/20/24 stations for each layer.
3. Main motor power: 7.5KW, one set, it adopts cycloid cone pulley reducer, chain transmission.
4. Material of the roller: 45# steel, chromeplate
WhatsApp:+8618830702960
|
Parameter Item
|
Specification
|
|---|---|
|
Applicable Materials
|
Galvanized steel, color-coated steel (PPGI/PPGL), aluminum-magnesium-manganese, stainless steel
|
|
Material Thickness
|
0.3-0.8mm (customizable 0.3-1.2mm)
|
|
Feeding Width
|
1000/1220/1250mm (customizable)
|
|
Number of Forming Layers
|
3 layers (independent operation)
|
|
Number of Forming Stations per Layer
|
16-24 stations
|
|
Roll Material
|
GCr15 forged steel, quenched and chrome-plated
|
|
Production Speed
|
10-25m/min per layer (adjustable independently)
|
|
Cutting Method
|
Hydraulic fixed-length cutting / flying shear (independent for each layer)
|
|
Control System
|
PLC + touch screen (Siemens/Delta), independent control for each layer
|
|
Total Power
|
15-22kW
|
|
Power Supply
|
380V/50Hz/3P (customizable)
|
|
Equipment Dimensions
|
Approx. 9500×2200×1800mm
|
|
Equipment Weight
|
5-10 tons
|
|
Cutting Precision
|
±1mm
|
|
Noise
|
≤75dB
|
|
Cooling/Lubrication
|
Air cooling / automatic centralized lubrication
|
|
Warranty
|
1 years for the whole machine, lifelong maintenance
|
At XINNUO, we are committed to delivering high-performance metal roll forming machines tailored for global industrial needs. Our equipment offers reliable and flexible production capabilities to meet the demands of modern construction and manufacturing industries.
